iPot-5K Normal Pressure Potting Product Series

产品特点:

1. Suitable for simple filling of self-flowing glue and complex 3D path filling.

2. Can handle glue with high filler.

3. High potting efficiency, up to 500 mm/s.

4. Multiple mixing valves can be equipped to meet CT requirements.

5. Trajectory path planning capability for point, line, circle, arc, etc.

6. With waste adhesive bonding device to keep the table clean.

技术规格:

Technical Parameters:
Semi-Automatic Normal Pressure Potting Machine
Model	iPot-5K1101
Work scope(mm)	600(X)×600(Y)×100(Z)
Movement speed(mm/s)	0-500
Repeatability(mm)	±0.05
Transmission mode	Servo motor +ball screw
Operating system	PC+motion control card
Operable viscosity	<100000cP
Purge precision	±0.2(10g reference)
Mixing ratio	1:1-10:1
Dispensing speed(g/s)	0.2 -12
Mixing mode	Dynamic/static optional
Measurement method	Piston pump/screw pump/gear pumr
Clarity	Fully automatic/Semi-automatic
Power supply	AC220V 8kW
Machine dimensions(mm)	1600(L)×1400(W)×2000(H)
Weight(kg)	≈50C
Work environment	Temperature:0-40 ℃;Relative humidity:20- 90%
